Technical Parameter


Model

PVC-16/63

PVC-20/110

PVC-50/160

PVC-75/250

PVC-110/315

PVC-200/450

PVC-315/630

PVC-500/800

Diameter

16-63mm

20-110mm

50-160mm

75-250mm

110-315mm

200-450mm

315-630mm

500-800mm

Max output

120kg/h

120kg/h

180kg/h

300kg/h

450kg/h

650kg/h

800kg/h

1400kg/h

Speed

1.5-15m/min

0.8-8m/min

0.5-5m/min

0.4-4m/min

0.3-2m/min

0.1-1m/min

0.07-0.7m/min

0.05-1 m/min

Extruder

SJZ-51/105

SJZ-51/105

SJZ-55/110

SJZ-65/132

SJZ-80/156

SJZ-92/188

SJZ-92/188

SJZ-105/220

Total power

45kw

45kw

55kw

75kw

105kw

160kw

205kw

305kw

Center height

1000mm

1000mm

1000mm

1000mm

1100mm

1100mm

1200mm

1350mm

Area

22*2.5*2.0m

24*2.8*2.0m

24*2.8*2.0m

30*2.8*2.2m

35*3.0*2.4 m

36*3.0*2.4 m

38*3.2*2.8 m

42*3.5*3.2 m


Product Description


Advantages of PVC pipes:


1. Excellent in chemical corrosion, no rust;

2. With self extinguishing and flame retardant;

3. Excellent in anti aging, can be used 20years to 50 years between the temperature from subzero 15 to 60 degrees Celsius;

4. Wall is smooth, inner wall surface tension, it is difficult to form scale, the fluid transport capacity of 43.7% higher than the cast iron pipe;

5. The weight is light, easy to flaring, bonding, bending, welding, pipe installation workload is only 1 / 2 to the steel pipes, low labor intensity, short duration;

6. Good electrical properties of resistance, volume resistance of 1 to 3 x 105Ω.cm, breakdown voltage 23 to 2kv/mm;

7. The toughness of PVC pipe is low, linear expansion coefficient is high, operating temperature range is narrow.
